Find Your Resistor
Technical Guides
Each series shares PRC’s proven enclosed shell construction with artificially aged resistance wire and pure copper terminals.
- Cross-Reference Guide
Find PRC equivalents for military and legacy commercial resistor parts.
- PRC100 Tracking Chart
Precision RTD temperature tracking data for the PRC100 series sensors.
- BALCO Tracking Chart
Standardized resistance- temperature curves for BALCO alloy wire elements.
Surface Mount Shunts
Surface Mount Design (SMD) "Carrier Tape" Packaging per IEC 286-3 (EIA 481):
Tape and Reel Physical Dimensions
On Reels:
2.750″ O.D. x 4″ I.D. x 1″ W – 1/2″ bore. Skin packed to board with polyfilm.
24mm (.945″W)-8mm pitch:
For types: HVS1, LVS1, PRC100T, PTS1, PVS1, & ST35
24mm (.945″W)-8mm pitch:
For types: HVS2, HVS3, LVS2, LVS3, PTS2, PTS3, PVS2, & PVS3
32mm (1.26″W)-12mm pitch:
For types: LVS5, PVS5 & HVS5
We also can tape and reel all standard axial lead resistors upon customer request.
Compliance & Certifications
RoHS Compliance Statement
REACH Declaration
Conflict Minerals Policy
All PRC products manufactured to ISO 9001:2015 standards and MIL-SPEC guidelines where applicable.
The Precision Wire-Wound Advantage
Why leading aerospace and medical manufacturers specify PRC wire-wound technology for critical circuits.
Ultimate Stability
Lowest TCR (Temperature Coefficient of Resistance) available, down to ±1ppm/°C.
High Pulse Capability
Robust wire element absorbs significant energy surges that destroy thin-film alternatives.
Unmatched Longevity
Hermetically sealed options for 20+ year service life in extreme environments.
Individual Series Datasheets
Single consolidated PDF per series — every part number, dimensional drawing, electrical specs, derating curves, and ordering information.
Why Wire Wound Shunts Outperform Alternatives
Low EMF construction (<0.3 to 1.5 μV/°C) vs up to 100 μV/°C in tin oxide alternatives
Superior overload and surge current handling capability
A single PRC shunt replaces 2+ thin film or metal strip parts
Pure copper terminals avoid thermocouple errors in low-value shunt applications
Critical for accurate voltage drop measurement in precision metering
Engineering Download Center
Access our master catalogs and manufacturing guidelines in PDF format.
Full Product Catalog
Download the complete PDF catalog
Solder Guidelines
PRC's recommended soldering procedures
Can't find the spec you need?
Our applications engineers respond within one business day. Custom values, tolerances, and form factors available — most projects qualify for free samples.
